DIY Stained Wood Raised Platform Bed Frame – Part 1

I’ve finally made some progress on my DIY stained wood raised platform bed frame.  I still need to add all of the pretty trim and stain the whole thing, but I at least got it to the point where it was usable last night.  And here’s what it looks like so far.

DIY wood bed frame 19

It’s definitely a step in the right direction, especially considering that this has been our master bedroom for the last two weeks.

wood bed frame - before

So luxurious, right?  😀  Yep, our mattress and box spring are just sitting right on the floor.  And yes, I’m using a step stool as a bedside table.  And yes, that is a soon-to-be-installed toilet in a box sitting to the side.  And yes, those are still the same blinds, window shade, and shelves that were here when we moved in.  So much to do, but I’m trying not to let myself get stressed out.  I want to enjoy the journey.

Anyway, here’s how I built the platform bed frame…

Tool & Supply List:

2 – 1″ x 8″ x 8′ pine boards*

2 – 1″ x 8″ x 6′ pine boards*

4 – 1″ x 2″ x 8′ pine boards*

4 – 1″ x 2″ x 6′ pine boards*

4 – 2″ x 3″ x 8′ boards

8 – 1″ x 4″ x 10′ boards

Wood glue

1 – 50-piece package #8 x 2-inch wood screws

Drill with drill bits and screwdriver bit

Brad nailer (this is the one I have) with 1 1/4-inch brads

Miter saw

Tape measure

4 – Heavy duty top plates for the decorative feet

4 – Decorative feet*

Choice of decorative trim*



*These pieces will show on the finished frame, so I made sure to choose high quality, super straight pieces of wood that will stain nicely (I hope).  The nice stuff costs quite a bit more, so if you’re going to upholster the bed frame, there’s no need in purchasing the pretty stuff.



Build the basic frame:

I started with 1″ x 8″ pine boards, and cut two of them to 60 inches long, and two of them to 81.5 inches long.  I attached one of the 60″ pieces to one of the 81.5″ pieces using wood glue and 2-inch wood screws.

DIY wood bed frame 1

You can see here that the wood screws went through the 81.5-inch piece, and into the end of the 60-inch piece.  I pre-drilled all of the holes to prevent cracking.

DIY wood bed frame 2

Then I attached the other 81.5-inch piece to the other side, again using wood glue and wood screws.

DIY wood bed frame 3

And finally, I attached the last 60-inch piece.

DIY wood bed frame 4

Add support pieces to the long sides of the frame:

Next I cut four 80-inch long pieces of 2″ x 3″ lumber.  I measured down 3 1/4 inches from the top of the frame, and aligned the top edge of the 2″ x 3″ lumber, and then attached it using wood glue and 2-inch wood screws.  I screwed them in from the inside towards the outside so they wouldn’t show on the outside finished bed frame.  I used a total of nine screws to attach the 2 by 3.  Then I repeated the process on the other side of the bed frame.

DIY wood bed frame 5

Add center support pieces:

Next I attached the two center support pieces.  I cut three spacer blocks (precisely 1 1/2-inches high) so that the center support pieces would be the same height as the side support pieces.  With the 2 by 3 resting on the spacer blocks, I attached the first one using wood glue on the ends of the support piece, and wood screws through the frame and into the end of the 2 by 3.  Then I used some scrap pieces of 2 by 3 wood (which would eventually be cut down and used as the center support legs) to properly space the support pieces, and attached the second center support piece using the same process.

DIY wood bed frame 6

You can see here that the screws are visible on the outside of the frame, but I did countersink them just a bit so that I can fill in with wood filler and sand it smooth before I stain the bed frame.  Also, on the headboard side that is against the wall, I used two screws into each support piece since they’ll be against the wall and won’t show anyway.

DIY wood bed frame 7

And here’s a better view.  You can see the spacer blocks that I cut to rest the support pieces on while I was attaching them.  And you can also see how I used scrap 2 by 3 pieces to space the center support pieces.  I later cut those scrap pieces down to use as the center legs.  (Since the center legs don’t show, there’s no need to spend money on more fancy legs for that area.)

DIY wood bed frame 8

Attach the bottom frame:

Next I turned the bed frame completely over, so that the bottom was on top.  Using 1″ x 2″ pine lumber, I cut pieces to create a frame around the bottom edges of the bed frame.  I mitered the corners like I would on a frame. The I used wood glue and 1 1/4-inch brad nails to attach the pieces.

DIY wood bed frame 9

Here’s how it looked once all four pieces were attached, creating a frame around the bottom edge of the bed frame.

DIY wood bed frame 10

Here’s a closer look at the frame effect with the mitered corners.

DIY wood bed frame 11

Attach the decorative feet:

Next I attached the metal plates that the cute little feet screw into.  I made very sure that I aligned the screws with the edge of the 1″ x 8″ wood that makes up the main frame.  (Note:  It looks like I didn’t space the metal plate properly on the right side, but that’s just because in the picture, the 1″ x 2″ piece of wood is blending into the 2″ x 3″ support piece that’s attached to the inside of the bed frame.  The left side of the metal plate shows more accurately how I aligned the plate.)

DIY wood bed frame 12

Once the plate was firmly attached, I could screw in the cute little feet.

DIY wood bed frame 13

Here’s how it looked with all four feet attached.

DIY wood bed frame 14

I also attached an anti-skid pad to each of the feet.

DIY wood bed frame 16

With the feet attached, I flipped the bed frame right side up.

DIY wood bed frame 15

Attach the center support feet:

Using those same two scrap pieces of 2 by 3 that I used earlier, I slid them between the two center support pieces, marked where they needed to be cut to make them flush with the top edges of the support pieces, and cut off the excess.  Then I attached them using wood glue and 2-inch wood screws that were screwed through the support pieces and into the legs from each direction.

DIY wood bed frame 17

(Sorry, but I didn’t get a picture of the legs after they were cut down and attached!!  But just imagine that all of the excess that’s sticking out of the top has been cut off so that the tops of the legs are flush with the top edges of the two support pieces.)

Add the support slats:

I cut 16 pieces of 1″ x 4″ pine to use as the slats.  I cut the pieces to just under 60 inches long, and then spaced them evenly (I didn’t measure the spacing — just eyeballed it).  Then I attached them with wood glue and 1 1/4-inch brad nails using my brad nailer.

DIY wood bed frame 18

At that point, I could add the mattress.

DIY wood bed frame 19

I started building at about 3:15pm yesterday afternoon, and got it to this point at 8:00pm, working by myself as usual.  I still want to add some pretty decorative trim, and then I’ll stain the whole thing.

I was a tad bit disappointed that I wasn’t able to finish all of the building (I was hoping to just have the staining left to do today), but that’s alright.  I’d say that even without the pretty trim, this is still far better than what we had before!  🙂

DIY wood bed frame 20

It’s a rainy day here today, but I’m still going to do my best to get this thing finished today so I can show you the finished bed frame tomorrow.  No promises, though.  🙂  And as you might have noticed, I’m going to do the headboard as a separate project.  It was imperative that I get the bed frame completed ASAP so that the bed can be at the correct height for Matt, but a headboard isn’t quite so imperative.
